Openflow SPCS Setup

Complete guide for setting up Snowflake Openflow using Snowpark Container Services (SPCS).

Prerequisites

This setup must be completed before configuring any Openflow connectors. This is typically a one-time setup per Snowflake environment performed by administrators.

Overview

Setting up Openflow - Snowflake Deployment involves four main tasks as outlined in the official Snowflake documentation:

Step	Task	Persona	Duration
1	Setup Core Snowflake	Snowflake Administrator	10 min
2	Create Deployment	Deployment Engineer / Administrator	5 min
3	Create Runtime Role	Data Engineer	5 min
4	Create Runtime	Data Engineer	5 min

Availability

Snowflake Openflow - Snowflake Deployments are available to all accounts in AWS and Azure Commercial Regions. This is a Preview Feature gradually rolling out to all accounts.

Available Connectors

Openflow supports 19+ connectors including Google Drive, Box, SharePoint, Kafka, MySQL, PostgreSQL, and more. For a complete list with descriptions, see Openflow connectors.

Additional Resources

Check out the companion GitHub repository which includes Jupyter notebooks demonstrating advanced Openflow configurations and use cases.

Step 1: Setup Core Snowflake

Before creating a deployment, configure core Snowflake components including the Openflow admin role, required privileges, and network configuration.

Create Openflow Admin Role

The OPENFLOW_ADMIN role is the primary administrative role for managing Openflow deployments:

-- Create the Openflow admin role (requires ACCOUNTADMIN or equivalent privileges)
USE ROLE ACCOUNTADMIN;
CREATE ROLE IF NOT EXISTS OPENFLOW_ADMIN;

-- Grant necessary privileges
GRANT CREATE DATABASE ON ACCOUNT TO ROLE OPENFLOW_ADMIN;
GRANT CREATE COMPUTE POOL ON ACCOUNT TO ROLE OPENFLOW_ADMIN;
GRANT CREATE INTEGRATION ON ACCOUNT TO ROLE OPENFLOW_ADMIN;
GRANT BIND SERVICE ENDPOINT ON ACCOUNT TO ROLE OPENFLOW_ADMIN;

-- Grant role to current user and ACCOUNTADMIN
GRANT ROLE OPENFLOW_ADMIN TO ROLE ACCOUNTADMIN;
GRANT ROLE OPENFLOW_ADMIN TO USER IDENTIFIER(CURRENT_USER());

Create Snowflake Deployments Network Rule

Create the required network rule for Openflow deployments to communicate with Snowflake services:

-- Switch to OPENFLOW_ADMIN role
USE ROLE OPENFLOW_ADMIN;

-- Create network rule for Snowflake Openflow deployments
CREATE OR REPLACE NETWORK RULE snowflake_deployment_network_rule
  MODE = EGRESS
  TYPE = IPV4
  VALUE_LIST = ('10.16.0.0/12');

-- Verify the network rule
DESC NETWORK RULE snowflake_deployment_network_rule;

Network Rule Configuration

This network rule is required for Openflow deployments to communicate with Snowflake's backend services. The IP range 10.16.0.0/12 provides access to Snowflake's Openflow infrastructure.

Reference Documentation

For detailed information, see Setup core Snowflake in the official documentation.

Step 2: Create Deployment

After configuring core Snowflake, create an Openflow deployment. This is the container environment where Openflow will run.

Access Openflow in Snowsight

1. Navigate to Openflow: Go to Work with data → Ingestion → Openflow
2. Openflow Interface: You'll see three tabs:
3. Overview - List of available connectors and documentation
4. Runtimes - Manage your runtime environments
5. Deployments - Create and manage Openflow deployments

Create Deployment

1. Navigate to Deployments Tab: Click on the Deployments tab
2. Create Deployment: Click Create Deployment button
3. Configure Deployment:
4. Deployment Name: FESTIVAL_OPS_DEPLOYMENT
5. Database: Select or create a database for Openflow metadata
6. Compute Pool: Select an existing compute pool or create new
7. Enable Event Table: (Optional) Enable for logging and monitoring

Optional: Configure Event Table

For advanced monitoring and troubleshooting:

-- Create event table for Openflow logs
USE ROLE OPENFLOW_ADMIN;
CREATE EVENT TABLE IF NOT EXISTS OPENFLOW_CONFIG.EVENTS.openflow_events;

-- Grant privileges
GRANT INSERT ON EVENT TABLE OPENFLOW_CONFIG.EVENTS.openflow_events TO ROLE OPENFLOW_ADMIN;

Verify Deployment Status

Check that your deployment is running via the Snowsight UI:

1. Navigate to Deployments Tab: Go to Work with data → Ingestion → Openflow → Deployments
2. Check Status: Look for FESTIVAL_OPS_DEPLOYMENT with status ACTIVE

Expected status: ACTIVE

Reference Documentation

For detailed information, see Create deployment in the official documentation.

Step 3: Create Runtime Role

After creating the deployment, create a runtime role with associated external access integrations. This role defines what external services your connectors can access.

Create Runtime Role

-- Create runtime role (requires ACCOUNTADMIN privileges)
USE ROLE ACCOUNTADMIN;
CREATE ROLE IF NOT EXISTS FESTIVAL_DEMO_ROLE;

-- Grant necessary privileges for database and schema
GRANT USAGE ON DATABASE OPENFLOW_FESTIVAL_DEMO TO ROLE FESTIVAL_DEMO_ROLE;
GRANT ALL PRIVILEGES ON SCHEMA OPENFLOW_FESTIVAL_DEMO.FESTIVAL_OPS TO ROLE FESTIVAL_DEMO_ROLE;
GRANT USAGE ON WAREHOUSE FESTIVAL_DEMO_S TO ROLE FESTIVAL_DEMO_ROLE;

-- Grant runtime role to Openflow admin
GRANT ROLE FESTIVAL_DEMO_ROLE TO ROLE OPENFLOW_ADMIN;

Configure Google Drive External Access Integration

Connector-Specific Configuration

The External Access Integration for Google Drive will be created in the next chapter modules when setting up the Openflow Connector for Google Drive. This integration configures the network rules required for the runtime to access Google Drive APIs.

What you'll configure in the next steps:

• Network Rules - Google API endpoints (admin.googleapis.com, oauth2.googleapis.com, etc.)
• Optional Workspace Domain - Your specific Google Workspace domain (e.g., your-company.com)
• External Access Integration - Combines network rules and grants to Openflow runtime

Preview the Configuration

All SQL snippets for Google Drive network configuration are available in sql/network.sql in the repository. You'll execute these as part of the connector setup in the following chapters.

Reference Documentation

For detailed information, see Create runtime role in the official documentation.

Step 4: Create Runtime

Create a runtime associated with the previously created runtime role. A runtime is the execution environment for your Openflow connectors.

Create Runtime via Snowsight

1. Navigate to Runtimes: Go to Work with data → Ingestion → Openflow → Runtimes tab
2. Create Runtime: Click Create Runtime
3. Configure Runtime:
4. Runtime Name: e.g., FESTIVAL_DOC_INTELLIGENCE
5. Runtime Role: Select FESTIVAL_DEMO_ROLE
6. External Access Integration: Select festival_ops_access_integration
7. Compute Pool: Select an existing compute pool

Verify Runtime Status

Check that your runtime is active via the Snowsight UI:

1. Navigate to Runtimes Tab: Go to Work with data → Ingestion → Openflow → Runtimes
2. Check Status: Look for FESTIVAL_DOC_INTELLIGENCE with status ACTIVE

Expected status: ACTIVE

Runtime Configuration

Database and schema configuration will be specified at the connector level when setting up individual connectors (e.g., Google Drive connector).

Reference Documentation

For detailed information, see Create runtime in the official documentation.

Next: Configure Google Drive Connector

With your Openflow SPCS infrastructure set up, you're ready to configure connectors to ingest data from external sources.

Continue with Quick Setup

For the Festival Operations demo, proceed to configure the Google Drive connector:

• Quick Setup Guide

  ---

  Complete end-to-end setup including Google Drive connector configuration, document upload, and Snowflake Intelligence

  Quick Setup

• Detailed Connector Guide

  ---

  Step-by-step visual guide with screenshots for configuring the Google Drive connector

  Connector Setup

Available Connectors

Openflow supports 19+ connectors including Google Drive, Box, SharePoint, Kafka, MySQL, PostgreSQL, and more. For a complete list, see Openflow connectors.

Troubleshooting

Deployment Not Starting

Issue: Deployment status stuck in CREATING or ERROR

Solutions:

• Verify compute pool is available and has sufficient resources
• Check OPENFLOW_ADMIN role has all required privileges
• Review event table logs for error details

Runtime Cannot Access External Services

Issue: Connector fails to connect to external services (e.g., Google Drive)

Solutions:

• Verify external access integration includes correct network rules
• Check runtime role has USAGE privilege on external access integration
• Ensure network rules include all required hostnames (Google APIs, workspace domain)

Permission Errors

Issue: "Insufficient privileges" errors when creating resources

Solutions:

• Verify you're using OPENFLOW_ADMIN or ACCOUNTADMIN role
• Check all grants were applied correctly in Step 1
• Ensure runtime role has necessary database/schema privileges

Summary

After completing this setup, you will have:

• ✅ OPENFLOW_ADMIN role - Administrative role with deployment and integration privileges
• ✅ Snowflake Deployments Network Rule - Required for Openflow to communicate with Snowflake services
• ✅ Openflow Deployment (FESTIVAL_OPS_DEPLOYMENT) - Container environment running in SPCS
• ✅ Runtime Role (FESTIVAL_DEMO_ROLE) - With database and warehouse access
• ✅ Active Runtime (FESTIVAL_DOC_INTELLIGENCE) - Ready to host connectors

You're now ready to configure the Google Drive connector and its External Access Integration!

Next Steps

Choose your path to complete the setup:

• Recommended: Quick Setup

  ---

  Complete end-to-end demo setup in 15 minutes

  Quick Setup Guide

• Detailed Setup

  ---

  Step-by-step visual guide for connector configuration

  Connector Setup
